The RCC Series coalescer cartridges are offered in a variety of cartridge configurations to replace current industry cartridges. They are available with double open ends and flat gaskets (ML-R spec), open ends with O-Ring seals, and thread base construction. Cartridges are available in a number of different diameters and lengths. All Royal Filter coalescers are single piece construction, resulting in increased strength and reducing the chance of bypass. We use a combination of one or more layers of pleated media and various layers of fiberglass. The pleated media removes the bulk of solids. Coalescing performance is determined by the type and number of layers of fiberglass.
RCC Series Coalescer Cartridges
Royal Filter can retrofit a number of OEM’s such as:
- Facet
- Fram
- Guardian Labs
- Jonell
- Kaydon
- Murphy
- Peco
- Racor(Parker)
- Velcon(Parker)
| Royal Coalescers are available in four different series of efficiency. These ratings are nominal and should be used for reference only: |
|||
| Series | Rated at | Normally used for | Removes water down to |
| 25 series | 25 micron | fuels such as diesel or heating oils. | 25 ppm |
| 5 series | 5 micro | place of the 25 series when more efficiency is or tighter filtration is desired. | 10 ppm |
| 2 series | 2 micron | lighter hydrocarbons such as kerosene, gasoline, or naphtha. | less than 5 ppm |
| 1 series | 1/2 to 1 micron | is designed for maximum coalescing and particulate removal efficiency | less than 5 ppm |
RSC Series Separator Cartridges
The RSC Separator cartridge are available in two different designs – silicon treated pleated cellulose and a Teflon® coated stainless steel screen.
The silicon treated resin impregnated cellulose media is designed to repel small coalesced water droplets that do not settle by gravity and pass through the separator. This pleated media provides effective 5 micron particulate filtration.
The Teflon coated screen separators are manufactured with 200 mesh stainless steel coated on both sides with Teflon. This media is hydrophobic allowing the hydrocarbon fluid to pass through while repelling the water droplets.
Center cores are perforated, plated steel. End caps are tin plated steel or glass reinforced nylon. Standard gaskets are Buna-N. Other gasket material are available upon request.
Royal Filter can retrofit a number of OEM’s such as:
- American Filter Tech
- Baldwin
- C&M Filtration
- Facet
- Guardian Labs
- Jonell (Filtration Group)
- Kaydon
- Murphy
- Peco
- Refilco
- Racor(Parker)
- Velcon (Parker)
